16mm, 24mm, 32mm, 50mm, 85mm and 100mm - all T2.1.
ARRI/Zeiss MK2 Standard Speed lenses have been the lenses of choice on many feature films, TVCs and other productions for four decades. Feature films such as The Shawshank Redemption, Holy Motors, Fargo and A Beautiful Mind were all shot with these lenses.
As with other vintage glass, Zeiss Standard Speed lenses are often chosen these days to 'soften' what many consider to be a harsher digital look. If you're trying to achieve a look that more modern lenses can't give you, come and shoot some tests on the Zeiss Standards.
For ARRI format coverage, including a video of coverage tests, please see our article here.
Please note that it is not reccomended to use these lenses with a clamp on mattebox as the focus mechanism will bind with too much weight on the front of the lens. You can use some ultralight matteboxes but please contact us to confirm compatibility.
A music video for Melbourne band The Seven Ups, filmed with Alexa 35 and Zeiss MKII Standard Speed lenses.
The team from SUIKA created this piece for Salomon AUS/NZ with ALEXA 35 and Zeiss Standard Speeds.
This test clip shows the coverage for each of the ARRI formats LF open gate, 4.3K LF 16:9, 3.8K LF 16:9, S35 open gate and S35 3.2K. Coverage can change as focus is racked, so we show that too.
Optical
Focal Length
16mm 24mm 32mm 50mm 85mm 100mm
Minimum Focus Distance
16mm: 0.25m (10") 24mm: 0.36m (1' 2") 32mm: 0.60m (2') 50mm: 0.46m (1' 6") 85mm: 0.91m (3') 100mm: 1.02m (3' 4")
Maximum Aperture
16mm: T2.1 24mm: T2.1 32mm: T2.1 50mm: T2.1 85mm: T2.1 100mm: T2.1
Minimum Aperture
16mm: T22 24mm: T22 32mm: T22 50mm: T22 85mm: T22 100mm: T22
Image Circle
16mm: ≅30mm 24mm: ≅31mm 32mm: ≅31mm 50mm: >45mm 85mm: >45mm 100mm: >45mm
Physical
Lens Mount
ARRI PL
Metadata
None
Focus / Iris Gear Pitch
0.8 mod
Front Diameter
16mm: 80mm 24mm: 80mm 32mm: 80mm 50mm: 80mm 85mm: 80mm 100mm: 80mm
Focus Ring Rotation
16mm: 340° 24mm: 340° 32mm: 340° 50mm: 340° 85mm: 340° 100mm: 340°
Dimensions (Ø x L)
16mm: 80 x 54mm 24mm: 80 x 54mm 32mm: 80 x 54mm 50mm: 80 x 54mm 85mm: 80 x 54mm 100mm: 80 x 130mm
Weight
16mm: 0.57kg 24mm: 0.57kg 32mm: 0.45kg 50mm: 0.57kg 85mm: 0.68kg 100mm: 0.88kg
Transport Case
Dimensions: TBD Weight (with lenses): TBD
