Cooke Speed Panchro Set (TLS) (6)
18mm S3 T2.2, 25mm S3 T2.2, 32mm S2 T2.3, 40mm S2 T2.3, 50mm S2 T2.3 and 75mm S2 T2.3.
The TLS rehousing of the vintage Cooke Speed Panchro lenses is widely considered the best available. The mechanics of this set look and feel very much like modern Cooke lenses, while the optics are the original Speed Panchro design.
For sensor coverage, please see our article and related video.
Contact us to arrange an inspection or lens test.
Telenova - Teardrop
DP Michael Lincoln chose ARRI Alexa 35 + TLS Cooke Speed Panchros for this Telenova music video.
Hafekasi
Cinematographer Matthew Chuang selected our Cooke Speed Panchros for this moving short film about a 10 year old girl and her cultural identity.
Ester
A conceptual piece from Director/DP Alexander Naughton to demonstrate our TLS rehoused Cooke Speed Panchro lenses. Shot on ARRI Alexa 35 with Trinity 2.
ARRI Sensor Coverage
This test clip shows the coverage for each of the ARRI formats LF Open Gate, 4.3K LF 16:9, 3.8K LF 16:9, S35 Open Gate and Alexa Mini 3.2K. Coverage changes as focus is racked, so we show that too.
Optical
Focal Length
18mm 25mm 32mm 40mm 50mm 75mm
Maximum Aperture
18mm: T2.2 25mm: T2.2 32mm: T2.3 40mm: T2.3 50mm: T2.3 75mm: T2.3
Minimum Aperture
18mm: T22 25mm: T22 32mm: T22 40mm: T22 50mm: T22 75mm: T22
Minimum Focus Distance
18mm: 0.20m (8") 25mm: 0.20m (8") 32mm: 0.23m (9") 40mm: 0.33m (1' 1") 50mm: 0.38m (1' 3") 75mm: 0.71m (2' 4")
Image Circle
18mm: 31mm 25mm: 34mm 32mm: 32mm 40mm: 38mm 50mm: 44mm 75mm: 45mm
Physical
Lens Mount
ARRI PL
Metadata
None
Focus Ring Rotation
280°
Focus / Iris Gear Pitch
0.8 mod
Front Diameter
18mm: 110mm 25mm: 110mm 32mm: 110mm 40mm: 110mm 50mm: 110mm 75mm: 110mm
Dimensions (Ø x L)
18mm: 110mm x 60.2mm 25mm: 110mm x 68.5mm 32mm: 110mm x 68.5mm 40mm: 110mm x 68.5mm 50mm: 110mm x 78.5mm 75mm: 110mm x 88.5mm
Weight
18mm: 0.82kg 25mm: 0.89kg 32mm: 0.84kg 40mm: 0.87kg 50mm: 1.03kg 75mm: 1.24kg
Transport Case
Dimensions: 650mm x 370mm x 220mm. Weight (with lenses): 13.5kg
