The Leica R cinemod lens set is a good option for full-frame vintage lenses, particularly if you are on a budget. Our set consists of a mix of Elmarit-R (f.2.8) and Summicron-R (f/2.0) lenses that were manufactered in the 1980s.
The set has been cinemodded to have uniform 80mm front diameters (all of which accept 77mm threaded filters) and an industry standard 0.8M focus ring for use with a follow focus.
A 60mm macro lens is part of the set which is great for capturing details with its 27cm minimum focus distance.
Please note that it is not reccomended to use these lenses with a clamp on mattebox as the focus mechanism will bind with too much weight on the front of the lens. You can use some ultralight matteboxes but please contact us to confirm compatibility.
DP David McKinnar photographed this music video for Allysha Joy with ARRI Alexa Mini and Leica R lenses.
Optical
Focal Length
24mm 35mm 50mm 60mm 90mm 135mm
Maximum Aperture
24mm: f/2.8 35mm: f/2.0 50mm: f/2.0 60mm: f/2.8 90mm: f/2.0 135mm: f/2.8
Minimum Aperture
24mm: f/22 35mm: f/16 50mm: f/16 60mm: f/22 90mm: f/16 135mm: f/22
Minimum Focus Distance
24mm: 0.30m (12") 35mm: 0.30m (12") 50mm: 0.50m (1' 8") 60mm: 0.27m (10") 90mm: 0.70m (2' 4") 135mm: 1.50m (4' 11")
Image Circle
24mm: 43mm 35mm: 43mm 50mm: 43mm 60mm: 43mm 90mm: 43mm 135mm: 43mm
Physical
Lens Mount
Canon EF
Metadata
None
Focus Ring Rotation
24mm: 130° 35mm: 270° 50mm: 270° 60mm: 330° 90mm: 300° 135mm: 250°
Focus Gear Pitch
0.8 mod
Front Diameter
24mm: 80mm 35mm: 80mm 50mm: 80mm 60mm: 80mm 90mm: 80mm 135mm: 80mm
Threaded Filter Size
77mm (all lenses)
Dimensions (Ø x L)
18mm: 95mm x 101mm 24mm: 80mm x 81mm 35mm: 80mm x 87mm 50mm: 80mm x 75mm 60mm: 80mm x 95mm 90mm: 80mm x 95mm 135mm: 80mm x 130mm
Weight
24mm: 488g 35mm: 558g 50mm: 422g 60mm: 527g 90mm: 675g 135mm: 864g
Transport Case
Dimensions: 450mm x 380mm x 190mm. Weight (with lenses): 7kg
