Canon C70 Kit
The C70 is a pocket rocket that packs a 4K Super 35mm sensor into a camera not much bigger than a DSLR.
10-bit 4K internal recording with 16+ stops of dynamic range gives you lots of latitude when you are edditing your footage and the C70 has all the Canon features you know and love from their other cinema cameras such as dual pixel autofocus and in-built ND filters.
This camera has a few new surprises as well. The native Canon RF mount means you can use Canon's latest range of lenses (the Canon RF 28-70 f/2 is worth a look) plus its shallow flange depth means it is easy to adapt to other lens mounts, such as Canon EF (this adapter is included) and Arri PL.
The new Dual Gain Output (DGO) sensor does a fantastic job of capturing a wide dynamic range making this camera fit nicely as the industry continues to expand into HDR.
Canon's colour science is fantastic and their current generation cinema cameras all match really well, making the C70 an ideal B camera for the Canon C300 MKIII or the Canon C500 MKII. If you are using it alongside a full frame camera you can also use the 0.71x Speedbooster adapter to maintain the same field of view.
No videos yet.
Lens Mount
Mount Options
Canon RF mount (native) Canon EF mount (with included adapter) Arri PL Mount (with optional adapter)
Flange Focal Depth
RF: 20mm EF: 44mm PL: 52mm
Imaging Sensor
Sensor Type
Super 35mm 9.6MP Dual Gain Output (DGO) CMOS Sensor with Dual Pixel Autofocus
Sensor Size
26.2 x 13.8mm. ⌀ 29.61mm.
Maximum Resolution
4096 x 2160 pixels.
Sensor Frame Rates
Full Sensor (Super 35): 14 - 120 fps. Super 16 crop: 15 - 180 fps.
Photosite Pitch
6.4 μm
Exposure Latitude
Canon Log 2: 16+ stops (at ISO 800) Canon Log 3: 14 stops (at ISO 800)
Lens Squeeze Factors
1.00x 1.30x 2.00x
Shutter
Electronic shutter. 11.25°- 360° (1/12s - 1/2000s).
Media & Recording Formats
Recording Media
SDXC UHS-II V90 media
Supported Formats
XF-AVC (MXF) ALL-I or Long GOP. MP4 H.265/HEVC MP4 H.264
Colour Coding
XF-AVC
10-bit YCbCr 4:2:2.
MP4 H.265/HEVC
10-bit YCbCr 4:2:2. 10-bit YCbCr 4:2:0.
MP4 H.264
8-bit YCbCr 4:2:0.
Colour Spaces
Rec 709 Rec 2020 Cinema Gamut
Recording Formats - XF-AVC
4K DCI
Clip resolution: 4096 x 2160px. Active photosites: 4096 x 2160px. Image area: 26.2 x 13.8mm. Image circle: ⌀29.61mm. ALL-I max FPS: 30. L.GOP max FPS: 120.
4K UHD
Clip resolution: 3840 x 2160px. Active photosites: 3840 x 2160px. Image area: 24.6 x 13.8mm. Image circle: ⌀28.20mm. ALL-I max FPS: 30. L.GOP max FPS: 120.
2K DCI
Clip resolution: 2048 x 1080px. Active photosites: 4096 x 2160px. Image area: 26.2 x 13.8mm. Image circle: ⌀29.61mm. ALL-I max FPS: 60. L.GOP max FPS: 120.
Full HD
Clip resolution: 1920 x 1080px Active photosites: 3840 x 2160px. Image area: 24.6 x 13.8mm. Image circle: ⌀28.20mm. ALL-I max FPS: 60. L.GOP max FPS: 120.
2K DCI (Super 16mm Crop)
Clip resolution: 2048 x 1080px. Active photosites: 2048 x 1080px. Image area: 12.3 x 7.4mm. Image circle: ⌀14.54mm. ALL-I max FPS: 60. L.GOP max FPS: 180.
Full HD (Super 16mm Crop)
Clip resolution: 1920 x 1080px. Active photosites: 1920 x 1080px. Image area: 11.7 x 7.4mm. Image circle: ⌀13.84mm. ALL-I max FPS: 60. L.GOP max FPS: 180.
Recording Formats - MP4 H.265 (HEVC)
4K DCI
Clip resolution: 4096 x 2160px. Active photosites: 4096 x 2160px. Image area: 26.2 x 13.8mm. Image circle: ⌀29.61mm. Max FPS: 120.
4K UHD
Clip resolution: 3840 x 2160px. Active photosites: 3840 x 2160px. Image area: 24.6 x 13.8mm. Image circle: ⌀28.20mm. Max FPS: 120.
2K DCI
Clip resolution: 2048 x 1080px. Active photosites: 4096 x 2160px. Image area: 26.2 x 13.8mm. Image circle: ⌀29.61mm. Max FPS: 120.
Full HD
Clip resolution: 1920 x 1080px Active photosites: 3840 x 2160px. Image area: 24.6 x 13.8mm. Image circle: ⌀28.20mm. Max FPS: 120.
2K DCI (Super 16mm Crop)
Clip resolution: 2048 x 1080px. Active photosites: 2048 x 1080px. Image area: 12.3 x 7.4mm. Image circle: ⌀14.54mm. Max FPS: 180.
Full HD (Super 16mm Crop)
Clip resolution: 1920 x 1080px. Active photosites: 1920 x 1080px. Image area: 11.7 x 7.4mm. Image circle: ⌀13.84mm. Max FPS: 180.
Recording Formats - MP4 H.264
4K DCI
Clip resolution: 4096 x 2160px. Active photosites: 4096 x 2160px. Image area: 26.2 x 13.8mm. Image circle: ⌀29.61mm. Max FPS: 120.
4K UHD
Clip resolution: 3840 x 2160px. Active photosites: 3840 x 2160px. Image area: 24.6 x 13.8mm. Image circle: ⌀28.20mm. Max FPS: 120.
2K DCI
Clip resolution: 2048 x 1080px. Active photosites: 4096 x 2160px. Image area: 26.2 x 13.8mm. Image circle: ⌀29.61mm. Max FPS: 120.
Full HD
Clip resolution: 1920 x 1080px Active photosites: 3840 x 2160px. Image area: 24.6 x 13.8mm. Image circle: ⌀28.20mm. Max FPS: 120.
2K DCI (Super 16mm Crop)
Clip resolution: 2048 x 1080px. Active photosites: 2048 x 1080px. Image area: 12.3 x 7.4mm. Image circle: ⌀14.54mm. Max FPS: 180.
Full HD (Super 16mm Crop)
Clip resolution: 1920 x 1080px. Active photosites: 1920 x 1080px. Image area: 11.7 x 7.4mm. Image circle: ⌀13.84mm. Max FPS: 180.
Viewfinder
Type
3.5" touchscreen LCD viewfinder
VF Display Type
LCD
VF Resolution
2.76M pixels
Audio
Recording Format
4 channel linear PCM, 24-bit 48 kHz
Input
2x Mini XLR with phantom power. 3.5mm stereo mini jack.
Output
3,5mm stereo headphone jack. HDMI (embedded).
Built-in Mics
Yes - one mono mic.
Other I/O
HDMI Out
HDMI Type A (full size).
Timecode
BNC jack.
Power
DC Input
24V DC In.
Battery Options
Canon BP-A30. Canon BP-A60.
Consumption
Max power consumption: 14.6W
Aux Outputs
None
Physical
Dimensions H x W x L
Body only - 160x 130 x 116mm. With Tilta cage - 300 x 250 x 150mm
Weight
Body Only - 1.19kg. With Tilta cage - 2.16kg.
