ARRI Amira Premium Kit
Superior ARRI image quality with unmatched versatility. From corporate to documentary, TVC to TV drama - the ARRI Amira is well suited to the task.
The Amira has the same sensor and colour science as the ARRI Alexa Mini, but in a body more suited to documentary / run and gun, or studio work. It has superior audio handling compared to the Alexa Mini, with XLR inputs and support for up to five channels of audio recorded with the image.
Amira pricing is indicative and is dependent on the type of package you need. Please ask us to quote on a kit that meets your specific requirements, or put together a quote yourself from our product range.
This is the Premium model - it has all available options, including 4K UHD and the latest version of the EVF (with improved optics).
Exterior Overview
A good run-through of the I/O and controls on the Arri Amira.
Camera Overview & Setup
A more in-depth look at the features of the Arri Amira and how to configure it.
Lens Mount
Mount Options
PL mount
Flange Focal Depth
52mm
Imaging Sensor
Sensor Type
Super 35 format ARRI ALEV III CMOS sensor with Bayer pattern color filter array
Sensor Size
26.40 x 14.85 mm. ⌀ 30.29 mm.
Maximum Resolution
3200 x 1800 pixels.
Sensor Frame Rates
0.75 - 200 fps
Photosite Pitch
8.25 μm
Exposure Latitude
14+ stops over the entire sensitivity range from EI 160 to EI 3200
Lens Squeeze Factors
1.00x 1.30x
Shutter
Electronic shutter, 5.0°- 356° or 1s - 1/8000s
Media & Recording Formats
Recording Media
CFast 2.0 cards
Supported Formats
Apple ProRes 4444 XQ Apple ProRes 4444 Apple ProRes 422 HQ Apple ProRes 422 Apple ProRes 422 LT MPEG-2 HD
Recording Modes
Standard real-time recording Pre-recording Intervalometer Stop Motion
Colour Coding
Apple ProRes 422 HQ
10bit YCbCr
Apple ProRes 4444
12bit YCbCr
AppleProRes 4444 XQ
12bit YCbCr
Colour Spaces
Rec 709 Rec 2020 Log C Custom Look (ARRI Look File ALF-2)
Recording Formats - Apple ProRes
ProRes 4K UHD
Clip resolution: 3840 x 2160px Active photosites: 3200 x 1800px Image area: 26.40 x 14.85mm Image circle: ⌀30.29mm Max FPS: 60
ProRes 3.2K
Clip resolution: 3200 x 1800px Active photosites: 3200 x 1800px Image area: 26.40 x 14.85mm Image circle: ⌀30.29mm Max FPS: 60
ProRes 2K
Clip resolution: 2048 x 1152px Active photosites: 2868 x 1612px Image area: 23.66 x 13.30mm Image circle: ⌀27.14mm Max FPS: 200
ProRes HD
Clip resolution: 1920 x 1080px Active photosites: 2880 x 1620px Image area: 23.76 x 13.37mm Image circle: ⌀27.76mm Max FPS: 200
ProRes S16 HD
Clip resolution: 1920 x 1080px Active photosites: 1600 x 900px Image area: 13.20 x 7.43mm Image circle: ⌀15.15mm Max FPS: 200
Viewfinder
Type
Multi Viewfinder MVF-1 with 3,2" flip-out monitor
EVF Display Type
OLED
Flip-Out Monitor Display Type
LCD
EVF Resolution
1280 x 720 pixels
Viewfinder Diopter
Adjustable from -5 to +5
Power
Input
10.5-34 V DC via 8-pin LEMO 10.5-24 V DC via on-board v-mount battery interface
Consumption
Min. 52W - max. 84W (camera body with MVF-1)
Aux Outputs
1x Fischer 3pin 24V RS 1x LEMO 2pin 12V 1x Hirose 4pin 12V 1x LEMO 6pin EXT 24V
Audio
Recording Format
2 channel linear PCM, 24-bit 48 kHz
Input
2x XLR 3pin Mic/Line Input with 48V Phantom Power, switchable to AES3 1x XLR 5pin mic/line level Input with 48V phantom power (line input max. level +24dBu correlating to 0dBFS) Bluetooth whisper track
Output
3,5mm stereo headphone jack Bluetooth audio SDI (embedded)
Built-in Mics
None
Physical
Dimensions H x W x L
149 x 139 x 309 mm (camera body with PL lens mount)
Weight
4.1kg (camera body with PL lens mount)
ARRI Amira Sensor Modes
A comparison of the sensor modes available in the ARRI Amira, including image circles, recording resolutions and maximum frame rates.
