Zeiss Compact Prime CP.3 Set (7)
Available in either Arri PL or Canon EF mount.
The CP.3s are the latest generation in the Compact Prime range from Zeiss. Compared to the previous CP.2s, they are smaller, they have new coatings for better flare control and they offer richer blacks, higher contrast images and more saturated colours.
The front diameters on the CP.3s are smaller at 95mm, versus 114mm on the CP.2s.
Focal lengths available from us are 15mm T2.9, 21mm T2.9, 28mm T2.1, 35mm T2.1, 50mm T2.1, 85mm T2.1 and 100mm T2.1.
Showreel
A CP.3 showreel from Zeiss demonstrating a variety of looks achieved through the use of the lenses.
Zeiss Marketing Video
A showcase of the Zeiss CP.3 lenses, including some underwater footage and BTS.
Miscreants
A short film and quick BTS on the Zeiss CP.3 lenses in use.
Case 10-86 - Short Film
Another short film demonstrating the use of Zeiss CP.3 lenses.
Discussion + Short Film
If you can get past the annoying music, you might find this somehwat interesting to learn how the CP.3 lenses differ from the earlier CP.2 family, plus there is a very short film to see them in use.
Short Film - Sony FX9 + Zeiss CP.3
A short film made using the Sony FX9 and Zeiss CP.3 lenses.
Quality Assurance
Zeiss shows us some of the extensive testing that goes into the design and development of their CP.3 lenses.
Optical
Focal Length
15mm 21mm 28mm 35mm 50mm 85mm 100mm
Minimum Focus Distance
15mm: 0.30m (12") 21mm: 0.30m (12") 28mm: 0.24m (10") 35mm: 0.30m (12") 50mm: 0.45m (1' 6") 85mm: 1.00m (3' 3") 100mm: 0.70m (2' 6")
Maximum Aperture
15mm: T2.9 21mm: T2.9 28mm: T2.1 35mm: T2.1 50mm: T2.1 85mm: T2.1 100mm: T2.1
Minimum Aperture
15mm: T22 21mm: T22 28mm: T22 35mm: T22 50mm: T22 85mm: T22 100mm: T22
Image Circle
15mm: 43mm 21mm: 43mm 28mm: 43mm 35mm: 43mm 50mm: 43mm 85mm: 43mm 100mm: 43mm
Physical
Lens Mount
Arri PL Canon EF
Metadata
None
Focus / Iris Gear Pitch
0.8 mod
Front Diameter
15mm: 95mm 21mm: 95mm 28mm: 95mm 35mm: 95mm 50mm: 95mm 85mm: 95mm 100mm: 95mm
Focus Ring Rotation
18mm: 300° 21mm: 300° 28mm: 300° 35mm: 300° 50mm: 300° 85mm: 300° 100mm: 300°
Dimensions (Ø x L)
15mm: 95mm x 84mm 21mm: 95mm x 84mm 28mm: 95mm x 84mm 35mm: 95mm x 84mm 50mm: 95mm x 84mm 85mm: 95mm x 84mm 100mm: 95mm x 127mm
Weight
15mm: 0.87kg 21mm: 0.82kg 28mm: 0.84kg 35mm: 0.80kg 50mm: 0.77kg 85mm: 0.88kg 100mm: 1.01kg
Transport Case
Dimensions: 500mm x 350mm x 220mm. Weight (with lenses): 14kg
