Nanlux Evoke 900C
The Evoke 900C is a powerful 940W, full colour LED light fixture that can produce particular colours (e.g. yellow) more saturated than RGBW/RGBWW fixtures thanks to its RGBLAC (red/green/blue/lime/amber/cyan) chip array.
In CCT mode, the Evoke 900C has an impressive Kelvin range of 1,800 to 20,000K.
The Evoke 900C also has advanced features that make it well suited to professional sets - like built-in LumenRadio CRMX support for wireless DMX, a built-in Lee gel library, and XY coordinate mode for precisely matching other sources.
CineD Review
CineD review the Evoke 900C from Nanlux.
Andrew Lock Review
Melbourne gaffer Andrew Lock takes his usual thorough look at the Evoke 900C.
Illuminance
Light Only (No Modifier) - 3200K
1m: 31,100 lux 3m: 4,000 lux
Light Only (No Modifier) - 5600K
1m: 31,600lux 3m: 4,260 lux
Light Only (No Modifier) - Red
1m: 6,020 lux 3m: 826 lux
Light Only (No Modifier) - Green
1m: 14,300 lux 3m: 1,900 lux
Light Only (No Modifier) - Blue
1m: 2,380 lux 3m: 311 lux
Light With 45° Reflector - 3200K
3m: 12,100 lux
Light With 45° Reflector - 5600K
3m: 12,800 lux
Light With 45° Reflector - Red
3m: 2,580 lux
Light With 45° Reflector - Green
3m: 5,740 lux
Light With 45° Reflector - Blue
3m: 1,200 lux
Light With FL-35YK Fresnel - 3200K
3m: 8,760 lux (flood) / 33,500 lux (spot)
Light With FL-35YK Fresnel - 5600K
3m: 9,260 lux (flood) / 36,000 lux (spot)
Light With FL-35YK Fresnel - Red
3m: 1,779 lux (flood) / 7,320 lux (spot)
Light With FL-35YK Fresnel - Green
3m: 4,350 lux (flood) / 15,900 lux (spot)
Light With FL-35YK Fresnel - Blue
3m: 758 lux (flood) / 2,780 lux (spot)
Colour
Colour Temperature
In CCT mode: 1,800K - 20,000K
Full RGB Colour
Yes, using an RGBLAC array.
Colour Accuracy
CRI 96 TLCI 96 TM-30 Rf 94 TM-30 Rg 100 SSI 73 at 5600K SSI 81 at 3200K
Control
Control Options
Onboard DMX512 (5-pin) Art-net / sACN LumenRadio CRMX Bluetooth via Nanlink app
Operating Modes
CCT Advanced HSI RGBW Gel XY Effect Source Effects
Effects
HUE Loop CCT Loop INT Loop Flash Pulse Storm Police Car TV Paparazzi Candle/Fire Disco Bad Bulb Firework Explosion Welding
Power
Consumption
≤940W maximum
Power Supply
AC 100-240V 50/60Hz
Physical
Modifier Attachment
NL Mount (not Bowens compatible).
Mounting Interface
Junior (1 1/8" / 28mm) pin.
Dimensions
Fixture: 343 x 241 x 211mm. PSU: 343 x 145 x 124mm.
Weight
Fixture: 7.7kg. PSU: 4.5kg.
Weather Resistance
IP55 rating for head and ballast.
