The DJI Transmission is a wireless transmission system designed specifically for filmmakers. This system allows you to transmit video footage directly from your camera to the wireless montitor, with virtually no latency.
With a range of up to 6 km (line of sight) and a maximum bitrate of 40 Mbps, the DJI Transmission is capable of transmitting high-quality video footage, even in challenging environments. Its compact and lightweight design makes it easy to carry and install, and it's compatible with a wide range of cameras.
Thanks to the DJI Transmission's powerful encryption and data transfer capabilities, you can be sure that your video footage is always secure and protected. And with a user-friendly interface that's easy to navigate, you can quickly adjust settings and make changes on the fly.
Whether you're a professional filmmaker or an aspiring videographer, the DJI Transmission is an useful tool that will help take your video production to the next level. With its advanced features and reliable performance, it's a great solution for capturing stunning footage from any location.
No videos yet.
Monitor
Resolution
1920x1200
Input
HDMI (Direct input) HDMI (From Transmitter) SDI (From Transmitter)
Brightness
1500 Nits
Wireless
Range
Up to 6km line of sight. The operating environment can significantly impact range.
Delay
68 ms at 1080p60
Operating Frequencies
Non DFS Frequency Band: 2.4000-2.4835 GHz 5.150-5.250 GHz 5.725-5.850 GHz DFS Frequency Band: 5.250-5.350 GHz 5.470-5.600 GHz 5.650-5.725 GHz
RF Power
2.4000-2.4835 GHz: <33 dBm (FCC) <20 dBm (SRRC/CE/MIC) 5.150-5.250 GHz: <23 dBm (FCC/SRRC/MIC) 5.250-5.350 GHz: <30 dBm (FCC) <23 dBm (SRRC/MIC) 5.470-5.600 GHz, 5.650-5.725 GHz: <30 dBm (FCC) <23 dBm (CE/MIC) 5.725-5.850 GHz: <33 dBm (FCC/SRRC) <14 dBm (CE)
Encryption
256-Bit AES
Format Support
Supported Video Formats
3G SDI: YCbCr 4:2:2 10-bit HDMI RGB 4:4:4 1080p: 24/25/30/50/60fps 1080i: 50/60fps 720p: 50/60fps
Audio
PCM
Power
Power Input
6-18 VDC via LEMO NP-ZF Battery Plate (4x Batteries Included)
Power Consumption
TX: 11W
Physical
Mounting
TX: 3x ¼”-20 female RX: 1x ¼”-20 female
Dimensions
TX: 165 x 170 x 45mm. Monitor: 195 x 170 x 52mm. Transport case: 430 x 350 x 180mm
Weight
TX: 530g Monitor: 810g Transport case: 5.7kg
