Available in ARRI PL or Canon EF mount.
Weighing just 2.2kg, the Canon CN-E 30-105mm compact zoom is a flexible workhorse. Designed to provide enough resolution for 4K cameras, it's suitable for use on a wide variety of digital motion cameras. With a minimum focus distance of just 0.6m, this is a lens you can use in tight working conditions.
Naturally, this is a lens designed for motion. Unlike many modern zoom lenses designed for stills use, this is a parfocal zoom - it holds focus throughout its zoom range. The 11 blade iris ensures a pleasing treatment of out of focus parts of a scene, and the generous and highly visible lens marks help you nail critical focusing.
The 114mm front diameter is a common industry size and ensures compatibility with a wide range of matte boxes and other lens accessories.
The CN-E 30-105mm covers Super 35mm sized sensors. It does not cover 35mm full frame sensors.
AbelCine introduces you to the Canon CN-E 15.5-47mm and 30-105mm compact zoom lenses.
Optical
Focal Length
30mm - 105mm
Zoom Ratio
3.5X
Maximum Aperture
T2.8 (no ramping)
Minimum Aperture
T22
Minimum Focus Distance
60cm (2')
Image Circle
34mm - 38mm
Physical
Lens Mount
Arri PL Canon EF
Front Diameter
114mm
Metadata
None
Focus Scale
Imperial
Focus Ring Rotation
300°
Focus / Iris Gear Pitch
0.8 mod
Dimensions (Ø x L)
PL: 114mm x 218mm EF: 114mm x 210mm
Weight
2.2kg
Transport Case
Dimensions: 420mm x 330mm x 175mm Weight (with lens): 6kg
