Atlas Mercury Set (3A)
The Mercury series is a family of 1.5X, full frame anamorphic lenses with deliberate character. They improve the usability of anamorphic lenses on a range of cameras with their smaller size, reduced close focus, and large format coverage.
This A set has 36mm, 42mm and 72mm focal lengths - all T2.2 max aperture and they are PL mount.
The 1.5X squeeze works well with both 4:3 sensors found in high end cameras like the more recent ARRI Alexas (giving a 2:1 aspect desqueeze) and the more common 16:9 sensors found in cheaper cameras (giving a 2.6:1 aspect desqueeze).
Introduction
An introduction to the Mercury 1.5X anamorphic series lenses from Atlas Lens Co.
Review + Samples
Cam Mackey shares some footage lensed with the Atlas Mercury lenses, as well as an opinion of how the Mercury lenses offer the character many people are looking for.
Optical
Squeeze Factor
1.5X
Focal Length
36mm 42mm 72mm
Minimum Focus Distance
36mm: 0.46m (18") 42mm: 0.56m (2') 72mm: 0.91m (3')
Maximum Aperture
36mm: T2.2 42mm: T2.2 72mm:T2.2
Minimum Aperture
36mm: T16 42mm: T16 72mm: T16
Image Circle
36mm: > 45mm 42mm: > 45mm 72mm: > 45mm
Physical
Lens Mount
ARRI PL
Metadata
None
Front Diameter
36mm: 95mm 42mm: 95mm 72mm: 95mm
Focus Ring Rotation
36mm: 270° 42mm: 270° 72mm: 270°
Focus / Iris Gear Pitch
0.8 mod
Dimensions (Ø x L)
36mm: 95mm x 126mm 42mm: 95mm x 126mm 72mm: 95mm x 126mm
Weight
36mm: 1.2kg 42mm: 1.1kg 72mm: 1.6kg
Transport Case
Dimensions: TBA. Weight (with lenses): TBA.
